DGET-2000LPH
DGET
8438400000
The commercial RO (reverse osmosis) plants are considered as the most cost effective water treatment systems, such that it cleans the water from contaminants and removes unwanted things like corrosive salts, non essential, metals and chemicals in the water.
Each part function of the drinking water purification system
S/N. | Commodity name | Application | Remark |
1 | Raw water tank | Store water, buffering pressure, overcome instability of supplying water by pipe, ensure to supply water stably and continuously for whole system | Customer provide for themselves, because big size will result in expensive freight. |
2 | Raw water pump or called booster pump (feed water pump) | Provide needed pressure for every pretreatment filter | We can provide CNP pumps or Grundfos pumps |
3 | Mechanical filter or called quartz sand filter or sand filter | We use fiber glass or stainless steel vessel as housing, fill quarts sand, it can filter big particles impurities, suspended substances, colloids etc. | We use China brand or WAVE CYBER brand |
4 | Activated carbon filter | We use fiber glass or stainless steel vessel as housing, fill activated carbon, remove color, odor, residual chlorine and organics substances. | We use China brand or WAVE CYBER brand |
5 | Water softener, demineralizer, or called Na+ exchanger | Adopt cation resin to soften water, cation resin will absorb Ca2+, Mg2+(main elements for composing scale), reduce hardness of raw water, System can make resin intelligently regenerate, recycling | We use China brand or WAVE CYBER brand |
6 | Antiscalant dosing system or PH regulating system | Dosing antiscalant into feed water, prevent the ro membranes from blocking, prolong the lifetime of RO membranes. Regulating PH to suitable range. | Italy SEKO dosing pump or German Prominent |
7 | Security filter or pp filter, or called PP sediment filter | prevent large particles, bacteria, viruses into RO membrane, accuracy is 5µm | Stainless steel housing or PVC housing |
8 | High pressure pump | Provide needed working pressure for RO system, ensure production capacity of pure water. | CNP pump, Grundfos optional |
9 | RO(reverse osmosis) system | Can remove particles, colloids, organic impurities, heavy metal ions, bacteria, virus, heat source etc. harmful substances and 99% dissolved salts. | RO membranes USA Filmtec Dow |
10 | CIP cleaning system | Cleaning RO membranes with chemicals | CNP pumps |
11 | Sterilizing device | UV sterilizer or ozone generator | BNP ozone |
Features of wholesale price reverse osmosis water system :
1. High rejection rate
2. Lower cost and easy operation.
3. Large Production capability, especially suitable
for commercial and industries.
4. Cleaning system is optional if necessary.
Standard Main Components of wholesale price reverse osmosis water system :
USA DOW Membranes
( 97% average salt rejection)
Raw water pump
Quartz sand filter
Activated carbon filter
Security filter
Scene valves
U-PVC pipe
Stainless steel rack
380V/50Hz/3P power
Reverse osmosis water system
FRP or Stainless steel vessel
Electronic Control System
Nanfang(CNP) High-pressure pump
Optional Components of wholesale price reverse osmosis water system :
UV sterilizer
Water Softener
Ozone Generator
Two-stage RO system
Regulating wheels
Dosing system
Automatic cleaning system
PE,stainless steel or FRP water tank
If you have interest,please feel freel to get in touch with me.
